AXP600FE Surface Panel
  • Overview
  • Features
  • Specifications
  • Application

AXP600FE product brochure

    AXP600FE openhole logging surface panel is a 4U high, 19"rackmount panel which integrates signal acquisition, data processing, downhole tool supply, cable function switching, data transmission, winch control, front computer and other system functions.

    ArenaPetro has developed AXP600, AXP600A, AXP600B, AXP600C, AXP600D, AXP600E, AXP600F and other models of AXP600 series products, the latest model is AXP600FE.

AXP600FE

    AXP600FE series openhole logging surface panel is an upgraded version of AXP600EE,  this version is focused on improving performance, manufacturability and compatibility(micro resistive imaging tool).

    Some micro resistive tool need  third DC power supply, ArenaPetro re-layout the chassis' structure and add a low-noise DC power supply, customers can choose to install as their actual requirement.

    AXP600FE also updates the materials which are at the end of their life cycle's, so that we can avoid the production and maintenance difficulties.

    Simultaneously, the front computer hardware are upgraded and firmware bugs are solved.

    Finally, AXP600FE optimized the cooling fan's noise issues, it uses 120mm×120mm large sized fan, and  a temperature and humidity control and PWM speed control module is added in this model.
